| Form Factor |
|---|
| 3U |
| Dimensions (Dx Wx H) |
|---|
| 660 x 430 x 132mm 26" x 16.9" x 5.2" |
| PSU Form Factor |
|---|
| Single or Redundant |
| Front Buttons |
|---|
| Power On/Off Alarm Mute System Reset 2 x USB 2.0 |
| Cooling Fans |
|---|
| Centre: 4x 80mm (T=32mm) hot Swap middle fans Rear: Optional: 2x 80mm (T=25mm) rear fans |
| HDD Backplane |
|---|
| 12Gb/s mini-SAS |
| Front Bezel |
|---|
| Optional |
| Weights |
|---|
|
| M/B Form Factor |
|---|
| Extended ATX (12” x 13”) CEB (12" x 10.5" ATX (12" x 9.6") |
| Drive Bays |
|---|
| External 5.25": 1 Internal 3.5": 1 3.5" Hot-swap: 12 Slim ODD: 1 |
| Indicators |
|---|
| 1 x Power Status LED 1 x HDD Activity LED 2 x LAN Activity LED 1 x Fan Failure & Overheat Warning |
| System Security |
|---|
| Intrusion Switch |
| Expansion Slots |
|---|
| 7x Full Height and Full Length 6 x Low Profile |
| Metal Thickness |
|---|
| SGCC 1.2mm |
To place an order, please make an enquiry using the 'Request More Information' form at the bottom of the page and one of our experienced sales team will contact you shortly.
Alternatively, you can call or email us and speak to one of our experienced technical sales team.
Tel: 01438 842 300
Email: sales@tmc-uk.com
There are no downloads available.
