Chenbro RM23612M2-L

12Gb/s 12-port mini-SAS backplane with smart fan control
Anti-vibration hot-swap middle fans and air flow management
Easy-swap 3-slot (Riser) or 7-slot (low profile) rear window
Two internal 2.5" drive bays for OS mirroring
HDD carrier for 2.5" or 3.5" drives
Front access info tag for easy server management
Supports 2U single and 1+1 redundant PSU

Loading The product configurator is being loaded...

* Required Fields

Product Specifications

Form Factor
2U
Dimensions (Dx Wx H)
660 x 430 x 88 (mm), 26” x 16.9” x 3.5”
PSU Form Factor
2U Single or Redundant
Front Buttons
Power On/Off, Alarm Mute, System Reset
Cooling Fans
Middle: 4x 80mm (T=38mm), PWM , Rear: 2x 40mm (Option)
HDD Backplane
12Gb/s Mini-SAS
Front Bezel
Option
Weights
Net Weight 11kg
Gross Weight 12.7 kg
M/B Form Factor
Extended ATX (12” x 13”)
Drive Bays
3.5" Hot-swap:12
Indicators
1x Power Status , 2x LAN Activity, 1x Fan Failure & Overheat
System Security
Intrusion Switch (Option)
Expansion Slots
1 line
Metal Thickness
1.2mm
Cubic Feet
4.98
Container Loading (Single Packing)
20':314, 40':638, 40'H:690
