Chenbro RM41300

  • Supports 8-slot rear window for 4 GPU cards (RM41300-FS81)
  • Truly isolated anti-vibration design on internal HDD and drive cages
  • Optional second 3 x 5.25” drive cage for maximum configuration flexibility
  • Dedicated 80mm fan for HDD cooling
  • Card retainer to hold low profile and full height add-on cards (RM41300)
  • Supports stand-alone installation via optional kit (RM41300)
  • Supports 1-door or 2-door front bezel configuration (RM41300)

Price available upon request.

Product Specifications

Form Factor
4U
Dimensions (Dx Wx H)
546 x 430 x 176 (mm)
21.5” x 16.9” x 6.9”
PSU Form Factor
PS/2 Single or Mini-redundant
Front Buttons
Power On/Off
Alarm Mute
System Reset
2x USB
Cooling Fans
Front: 1x 120mm (T=25mm), PWM
Rear: 2x 80mm (Optional)
HDD Backplane
N/A
Front Bezel
Optional
Weights
Net Weight: 12.5kg
Gross Weight:  15.5kg
M/B Form Factor
Extended ATX (12” x 13”)
Drive Bays
External 3.5":1
External 5.25":1
Slim ODD:1
Internal 3.5":1
Indicators
1x Power Status
1x HDD Activity
2x LAN Activity
System Security
Intrusion Switch
Key lock on front door
Expansion Slots
7, 8 (RM41300G) or
15 x Full Height and Full Length
Metal Thickness
1.2mm
Cubic Feet
4
Container Loading (Single Packing)
20’: 224
40’: 476
40’H: 544

How to Order

To place an order, please make an enquiry using the 'Request More Information' form at the bottom of the page and one of our experienced sales team will contact you shortly.

Alternatively, you can call or email us and speak to one of our experienced technical sales team.

Tel: 01438 842 300
Email: sales@tmc-uk.com
