Chenbro RM23512E2

12-Bay 3.5" with 12Gbps Expander backplane
3x 80mm Hot-swap PWM middle fans
Anti-vibration mechanism design for middle fan bar
7-slot (LP) rear windows
Supports 2U single or 1+1 redundant PSU

Loading The product configurator is being loaded...

* Required Fields

Product Specifications

Form Factor
2U
Dimensions (Dx Wx H)
699 x 432 x 88 (mm), 27.5” x 17” x 3.5”
PSU Form Factor
2U Single or 1+1 Redundant
Front Buttons
Power On/Off, Alarm Mute, System Reset, 2 x USB 2.0
Cooling Fans
Middle: 3 x 80mm (T=38mm), PMW, Hot-swap , Rear: 2 x 40mm (Option)
HDD Backplane
12Gb/s mini-SAS with expander on-board
Front Bezel
Option
Weights
Net Weight 13.8kg
Gross Weight 17.6kg
M/B Form Factor
Extended ATX (12”x13”)
Drive Bays
3.5" Hot-swap:12
Indicators
1 x Power Status, 1 x HDD Activity, 2 x LAN Activity , 1 x Fan Failure and Overheat
System Security
Intrusion Switch
Expansion Slots
3x Full Height and Full Length or 7 x Low Profile
Metal Thickness
1.2mm
Cubic Feet
4.72
Container Loading (Single Packing)
20’: 211, 40’: 433, 40’H: 479
