| Form Factor |
|---|
| 2U |
| Dimensions (Dx Wx H) |
|---|
| 457.2 x 430 x 88.1 (mm) , 18” x 16.9” x 3.5” |
| PSU Form Factor |
|---|
| PS/2 (front) |
| Front Buttons |
|---|
| Power On/Off, System Reset, 2 x USB 2.0 |
| Cooling Fans |
|---|
| Front: 1 x 80 (T=32mm) ( option ) , Rear: 1 x 80 (T=32mm), 2 x 40 (T=28mm) (option) |
| HDD Backplane |
|---|
| N/A |
| Front Bezel |
|---|
| Aluminum bezel frame or two-door bezel with air filter |
| Weights |
|---|
|
| M/B Form Factor |
|---|
| ATX (12” x 9.6”) |
| Drive Bays |
|---|
| External 5.25"：1 External 3.5"：1 Internal 3.5"：2 Internal 2.5"：2 |
| Indicators |
|---|
| 1x Power Status, 1x HDD Activity, 2x LAN Activity |
| System Security |
|---|
| Intrusion switch (option) |
| Expansion Slots |
|---|
| 3 x Full High PCI or 7 x Low Profile PCI |
| Metal Thickness |
|---|
| 1.0mm |
| Cubic Feet |
|---|
| 2.5 |
| Container Loading (Single Packing) |
|---|
| 20’: 388, 40’: 788, 40’H: 940 |
To place an order, please make an enquiry using the 'Request More Information' form at the bottom of the page and one of our experienced sales team will contact you shortly.
Alternatively, you can call or email us and speak to one of our experienced technical sales team.
Tel: 01438 842 300
Email: sales@tmc-uk.com
There are no downloads available.
Chenbro RM24100-L2 configured with:
No configuration yet
