SK31101

1. Fits chassis with one 5.25" drive bay

2. Top opening to deliver HDD cooling through system fans

3. HDD failure and activity indicators on the hot-swap drive carrier

4. Supports inrush current control for drive hot-swapping

5. Supports HDD failure single input from RAID or Expander card

6. Key lock for HDD security

Price available upon request.

Product Specifications

Product SKUs
SK31101
Dimensions (Dx Wx H)
171 x 146 x 43 (mm) 6.73" x 5.8" x 1.6"
Drive Bays
3.5" SATA/SAS HDD Tray x 1
Indicators
Power ON/OFF LED HDD Failure LED
Front Buttons
Key Lock
Cooling Fans
N / A
Backplane
6Gb/s SAS & SATA
Connectors (To Drive)
1 x (22+7) pins SAS connector
Connectors (To Host)
1 x 7 pins SAS connector
Net Weight
0.5 Kg

How to Order

To place an order, please make an enquiry using the 'Request More Information' form at the bottom of the page and one of our experienced sales team will contact you shortly.

Alternatively, you can call or email us and speak to one of our experienced technical sales team.

Tel: 01438 842 300
Email: sales@tmc-uk.com

There are no downloads available.
