SK51101

1. Fits chassis with slim FDD bay

2. Compatible with 2.5" SATA HDD or SSD thickness under 9.5mm

3. Supports HDD activity and failure indicators on front panel

4. Supports inrush current control for HDD hot-swapping

5. Reserved space for HDD ID label on front panel of HDD carrier

Price available upon request.

Product Specifications

Product SKUs
SK51101
Dimensions (Dx Wx H)
130 x 96 x 12.7 (mm) 5.12" x 3.78" x 0.5"
Drive Bays
1 x 2.5" Hot-swap SATA HDD and SSD bay
Indicators
Power ON/OFF LED Fan and HDD Failure LED
Front Buttons
NA
Cooling Fans
NA
Backplane
SATAIII
Connectors (To Drive)
1 x (22+7) pins SATA connector
Connectors (To Host)
1 x 7 pins SATA connector
Net Weight
  0.2 Kg

How to Order

To place an order, please make an enquiry using the 'Request More Information' form at the bottom of the page and one of our experienced sales team will contact you shortly.

Alternatively, you can call or email us and speak to one of our experienced technical sales team.

Tel: 01438 842 300
Email: sales@tmc-uk.com

There are no downloads available.
