| Product SKUs |
|---|
| SSG-640SP-DE1CR90 | Petascale All-Flash Storage Server |
| Motherboard |
|---|
| Super X12DSC-6 |
| Processor (per Node) |
|---|
| CPU |
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors |
| Core Count | Up to 36C/72T; Up to 54MB Cache per CPU |
| Note | Supports 120W - 205W TDP CPUs (Air Cooled) |
| System Memory (per Node) |
|---|
| Memory |
Slot Count: 16 DIMM slots Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM View Memory Options |
| Memory Voltage | 1.2V |
| On-Board Devices (per Node) |
|---|
| Network Connectivity |
2 RJ45 10GBASE-T View AOC Options |
| Input / Output (per Node) |
|---|
| LAN |
1 RJ45 1 GbE Dedicated BMC LAN port 2 RJ45 10 GBASE-T LAN ports |
| USB | 2 USB 3.0 ports (rear) |
| Video | 1 VGA port |
| DOM | 2 SuperDOM (Disk on Module) ports |
| System BIOS |
|---|
| BIOS Type | AMI 128MB SPI Flash EEPROM |
| Management |
|---|
| Software |
SuperCloud Composer® Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! |
| Power Configurations |
Power-on mode for AC power recovery ACPI Power Management |
| Security |
|---|
| Hardware |
Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features |
Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery System Lockdown |
| PC Health Monitoring |
|---|
| CPU |
4+1 Phase-switching voltage regulator Monitors for CPU Cores, Chipset Voltages, Memory |
| FAN |
Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control |
| Temperature |
Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis |
|---|
| Form Factor | 4U Rackmount |
| Model | CSE-947HTS-R2K63P |
| Dimensions and Weight |
|---|
| Height | 6.96" (177 mm) |
| Width | 17.6" (447 mm) |
| Depth | 43.3" (1099 mm) |
| Package | N/A |
| Weight |
Gross Weight: 225 lbs (102.06 kg) Net Weight: 130 lbs (58.97 kg) |
| Palletized Packing (W x H x L) | 35.82" (910 mm) x 29.92" (755 mm) x 53.15" (1345 mm) |
| Available Colour | N/A |
| Expansion Slots (per Node) |
|---|
| PCI-Express (PCIe) Configuration |
Default 3 PCIe 4.0 x16 LP slots View AOC Options |
| Drive Bays / Storage (per Node) |
|---|
| Drive Bays Configuration |
Default: Total 47 bays 2 internal fixed 2.5" SATA drive bays 45 top-loading hot-swap 3.5"/2.5" SAS/SATA drive bays View Drive Options |
| M.2 |
2 M.2 NVMe slots (M-key) View M.2 Options |
| System Cooling |
|---|
| Fans | Up to 6 Heavy Duty 8cm Fan(s) |
| Air Shroud | 1 Air Shroud |
| Power Supply |
|---|
| 2x 2600W Redundant Titanium Level (96%) Hot-plug power supplies | |
| Dimension (WxHxL) | 73.5 x 40 x 265 mm |
| Input |
2600W: 200-240Vac 2600W: 200-240Vdc (For CQC Only) 2600W: 200-240Vac / 50-60Hz 2600W: 200-240Vdc / 50-60Hz (for CQC only) |
| +12V |
Max: 216A / Min: 0A (11.4Vdc-12.6Vdc) (12V output) Max: 216A / Min: 0A (200Vac-240Vac) |
| 12V SB | Max: 3.5A |
| Output Type | Backplanes (gold finger) |
| Operating Environment |
|---|
| ROHS | RoHS Compliant |
| Environmental Spec. |
Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing) |
